Expected to be restocked by 1st week of May
Talk to a Headphone Guru
Club Audiophile
Club Audiophile
Join Club Audiophile to begin your pursuit of great sound. Earn points and save on every purchase.
READ MORE
While this product is out of stock, consider...
Designed in
Serbia
Ideal for Audiophiles
These DAC & Amps are designed for discerning music lovers. If audio quality is important to you, a set of DAC & Amps like these would be ideal.
You can expect these DAC & Amps to present you with a refined listening experience. The audio quality exhibited by these DAC & Amps is a beautiful mix of musicality, technical brilliance and high precision.
These DAC & Amps deliver a spacious & open soundstage that makes you feel you are sitting at a live concert. Experience the magic and delve into pure sonic tranquility!
Ideal for
Desktop Use
4.4mm
Balanced Output
Connect With
RCA & 4.4mm
Upto 3.8W @ 32Ω
Power Output
Metal
Build
Volume Controls
If your DAC & Amps include volume controls or volume rockers, you can easily change the volume with a button press or volume knob turn.
DAC & Amps that have volume controls make its operation incredibly simple; turn up the volume on your smartphone or your source devices and then change the volume on DAC & Amps to the desired level.
This design feature allows you to have complete control over the desired volume according to your listening preferences.
DESCRIPTION
EARMEN TAKES A BIG LEAP BY PRESENTING THEIR ALL-NEW CH-AMP
EarMen is known for its portable products, which have been highly successful in the audiophile community. EarMen, this time around, has taken it a step further and developed a specially designed fully balanced headphone amp & preamp that will give you a unique and pleasurable listening experience. The CH-Amp has high-tech components loaded in its circuitry with excellent features and a linear power supply unit.
FEATURES A COMPOSITE AMPLIFIER TOPOLOGY FOR A CLEAN PERFORMANCE
EarMen has implemented a Composite Amplifier Topology in the CH-Amp. Composite op-amp brings the best of both worlds with excellent DC and AC characteristics. These amplifiers offer several advantages over other types of amplifiers. The design engineers at EarMen have used Composite Amplifier Topology in the CH-Amp for a reason which helps bring out the best. Power amplifiers typically use thermal feedback loops, thus causing errors while driving heavy loads. These errors occur due to self-heating. Using the composite amplifier topology removes such errors and improves the performance of the circuitry. The composite amplifiers also offer better DC output offset.
DOUBLES-UP AS A PREAMP WITH GAIN SWITCH
Preamp outs and gain control are two significant features of the EarMen CH-Amp. You can connect powered monitors to CH-Amp's balanced or single-ended preamp outputs for a high-fidelity system. To better match your headphones, the gain switch provides you with better control over output volume and impedance.
HIGH-TECH COMPONENTS FOR A TRULY HI-FIDELITY SOUND
A team of engineers at EarMen have incorporated WIMA capacitors with audio electrolytes in combination with MELF low noise resistors and SoundPlus OPA1642 operational amplifiers, which proved to be great for getting neutral sound. EarMen CH-Amp has excellent characteristics, a low signal-to-noise ratio and THD, excellent frequency response and a lot of power.
FULLY BALANCED ARCHITECTURE WITH EXTRA LOW NOISE LINEAR POWER SUPPLY
EarMen CH-Amp is a fully Balanced Headphone Amplifier, which means that the balanced outputs from the source go to the output intact, only amplified. From the Single-end input, the signals are converted to balanced without phase shift (phase imbalance), obtaining + and - signals perfectly in phase. In this way, unwanted noise is removed, preventing them from being added inside the device. With the CH-Amp, you also get a linear low-noise power supply made without compromise, using the best components and the latest circuit design. EarMen Linear power supply is reliable, simplistic and produces minimal noise. It is designed to offer the best characteristics and efficiency. It also has protection against current overload, short circuits and thermal overload. The advantage of this power supply is that you can connect it to the EarMen Tradutto DAC and EarMen Staccato Streamer and get an all-in-one system.
EXQUISITE WORKMANSHIP WITH A COMPACT DESIGN
The EarMen CH-Amp is born from a full-block aluminium chassis, which makes it durable and robust. Its small size makes it suitable for any setting, system, or house. The PCB is encased in sturdy aluminium housing, which provides the board with more internal protection and external insulation.
SPECS
INPUTS | L1: RCA Single End Input L2: RCA Single End Input L3: Balanced 4.4 mm |
INPUT SENSITIVITY | RCA Single End Input = 2V Balanced 4.4 mm = 4V |
OUTPUTS | 6.35mm Single-Ended Balanced 4.4mm |
OUTPUT IMPEDANCE | <1 Ω |
PRE OUTPUTS | RCA (SE output) Balanced 4.4mm |
DIMENSIONS | 150x30x150 mm / 5,9"x1,18"x5,9" |
WEIGHT | 550 gr / 1,21lbs |
PSU DIMENSIONS | 150x60x150 mm / 5,9"x2,36"x5,9" |
PSU WEIGHT | 1590 gr / 3,52 lbs |
OUTPUT LEVEL | SE Input: 7Vrms BAL Input: 11Vrms |
MAX POWER | SE Input: 1.5 W BAL Input: 3.8 W |
THD+N | SE Input: 0.0008% BAL Input: 0.0005% |
SNR | SE Input: >116dB BAL Input: >118dB |
FREQ. RESPONSE | SE Input: ±0.005dB BAL Input: ±0.005dB |
OUTPUT LEVEL | SE Input: 7Vrms BAL Input: 11Vrms |
MAX POWER | SE Input: 1.5 W BAL Input: 3.8 W |
THD+N | SE Input: 0.0008% BAL Input: 0.0007% |
SNR | SE Input: >118dB BAL Input: >119dB |
FREQ. RESPONSE | SE Input: ±0.005dB BAL Input: ±0.005dB |
OUTPUT LEVEL | Single-end Output: 4V
Balanced output: 8V |
OUTPUT IMPEDANCE | Single-end Output: 100Ω
Balanced output: 200Ω |
SE 6.35MM | High: 7V (1.5W / 32Ω) Low: 2.9V (260mW / 32Ω) |
BALANCED 4.4MM | High: 11V (3.8W / 32Ω) Low: 5.5 V (1W / 32Ω) |
BOX CONTENTS | 1. EarMen CH-Amp |
2. Linear Power Supply | |
3. Remote Control | |
4. User Manual |
GENERIC NAME | Headphone Amplifier |
COUNTRY OF ORIGIN | Serbia |
IMPORTER DETAILS | Importers Name: Ferrari Video Address: 63/18, 1st Main Road, Gandhi Nagar, Chennai - 600020 Contact No: 044-24420733 |
NET QUANTITY | 1 |
