xDuoo
xDuoo - XA-10
Desktop Digital To Analog Converter (DAC)24 Hours
Chi-Fi
Excellence
1 Year of
Warranty
Ideal for
Indoor Use
Bluetooth with
aptX HD & LDAC
4-Pin XLR & 4.4mm
Balanced Output
Connect With
USB, Optical & Coaxial
Upto 4000mW @ 32Ω
Power Output
Dual AKM AK4493
Dual DAC Chip
DUOOL DACS, DUOOL AMPS EQUAL DOUBLE THE FUN
xDuoo XA-10 is equipped with two DAC (Digital To Analog Converter) and double amplifier chips. It also has a full output from decoding to amp circuit, which eliminates any noise interference and crosstalk between sounds and also background noise ensuring clean sound.

Reduced THD for a Clean, Distortion Free Sound And Built-In Relay Protection to Avoid POP Noises
The technology used in XA-10 reduces THD (Total Harmonic Distortion) down to a mere 0.0008%. What this means is the output is the cleanest possible signal without any audible artifacts. The device also has a crosstalk upto 108 dB, The S/N upto 120 dB and yet the noise is almost inaudible. The device also has built-in relay protection to avoid POP noises when it is turned on and this protects the earphone and unit under undesirable conditions.

Dual AK4493EQ chip and a Balanced Class-A Buffer to Ensure High Fidelity Sound
xDuoo has carefully selected the best components, chips, and high-end capacitors to ensure high-fidelity sound quality. xDuoo XA-10 uses transistors as a Class A buffer to keep the circuit in the best working condition at all times. This enables the unit to handle powerful outputs and strong load capacity efficiently. This is specifically designed to tackle output issues with various difficult headphones. The unit houses dual-chip AK4493EQ as the decoding chip which makes the sound quality pristine. Professional power chips adopt CPLD for data reshaping, accurate clock synchronization, and reduced jitter. The capacitors used in XA-10 adopt NICHICON, ELNA capacitance which has a smooth and warm sound with a sparkling high-end response.


Multi-Input Capabilities Supporting High-Definition USB Audio and Bluetooth Input
xDuoo XA-10 can be connected to the USB interface of a computer, mobile phone, tablet and HIFI players for easy use. The unit can be even connected to desktop CD players and various digital turntables via HD coaxial or optical input. The device can also be connected to various Bluetooth playback devices with support for SBC, AAC, aptX, aptX_LL, apt_HD and LDAC format transmission.

Multi-Output Interface With Output Power Upto 4000mW
With the xDuoo XA-10 it is possible to connect the unit with multiple choices of output - 6.5 single-ended output which powers upto 3000mW, 4 Pin XLR balanced output which powers upto 4000mW & 4.4 balanced output which also powers upto 4000mW.


DSD, MQA nad PCM Formats Supported
The xDuoo XA-10 is capable of supporting numerous format of audio including DSD format with maximum support upto dsd512, DXD format with maximum support sampling rate of 32bit/384khz, MQA format with maximum sampling rate of 32bit/384khz and PCM formats with a maximum sampling rate of 32bit/768khz. This enables you to enjoy music at the highest quality without any output restrictions.


Digital Volume Adjustment With High Definition OLED Display
Using two TI’s professional volume ICs, the distortion level is reduced to a minimum. The unit sports a 0.96 inch high-definition OLED display. The capability of 100-level volume can be fine tuned to the level you want. This allows the user to ensure that the device is tuned to the best decoding state at any given time.

SCREEN | 0.96 inch OLED |
HEADPONE IMPEDANCE | 16-600Ω |
OUTPUT POWER | Balance: 4000 mW (32Ω@1 kHz) Single-Ended: 3000 mW (32Ω@1 kHz) |
SNR | Balance: 120 dB Single-Ended: 115dB |
CROSSTALK | Balance: 108dB Single-Ended: 73dB |
THD+N | 0.0008% |
OUTPUT POWER | 500 mW (32Ω load) |
GAIN | +18dB |
VOLUME VALUE | 100 levels |
USB IN | PCM 16-32 Bit/44.1k - 768kHz, DSD64-512 DXD: 24-32 Bit/352.8k - 384kHz MQA: 16-32 Bit/44.1k-384kHz |
OPTICAL/COAXIAL IN | PCM 16-24 BIT/44.1-192kHz, DSD64 |
BLUETOOTH FORMAT | SBC, AAC, aptX, aptX HD, aptX LL, LDAC |
POWER SUPPLY | DC12V/3A |
BOX CONTENTS | 1. xDuoo - XA-10 |
GENERIC NAME | Headphone Amplifier |
IMPORTER DETAILS | Importers Name: Ferrari Video Address: 63/18, 1st Main Road, Gandhi Nagar, Chennai - 600020 Contact No: 044-24420733 |
NET QUANTITY | 1 |
1 Year Warranty
Don't sweat it, this xDuoo - XA-10 comes with a warranty
from xDuoo that covers manufacturing defects.
All products featured on Headphone Zone are backed by an original manufacturer's warranty.
Read more about xDuoo's warranty in India.
"The xDuoo XA-10 is an all-in-one unit that crammed everything into a small device. It has a very capable DAC with MQA full decoding capability, with a warm tonality and an energetic sense of attack."
Read More"xDuoo’s XA-10 is a good device that has excellent build quality, a unique design, and a sweet sound signature. For an all-in-one device that takes little desk space, the XA-10 may be your savior."
Read More"Considering its dual-mono and fully-balanced digital and analog sections and its discrete Class-A headphone amplifier section, it gets my highest recommendation and my highest award!"
Read More"The xDuoo XA-10 is a powerful and solid sounding Desktop DAC/Amplifier with a compact size that offers a very wide variety of connectivity options. Solid Overall Sound Performance."
